Technical Specifications
Actuator size     13.5 mm
Ambient temperature range [max]     80 °C
Ambient temperature range [min]     -40 °C
Ambient temperature range [max]     175 °F
Ambient temperature range [min]     -40 °F
Approval     CE, EAC, LLC CDC TYSK
CE evaluated     Yes
China RoHS compliance     Out of scope
China RoHS exemption clause     No
Coil connection     DIN Spade
Coil design standard     VDE 0580
Coil fastening     Clip-on
Coil winding insulation class     Class H to IEC 85
Colour     Blue
Compliance     EN 60730-1
Contains batteries     No
Duty rating     Continuous
EEE category     5 small equipment (any external dimension < 50 cm)
Electrical connection     DIN Spade
Electrical connection size     6.3 mm x 0.8 mm
Electrical connection standard     EN175301-803
Electrical connector     3 x spades
Enclosure rating      IP20
EU RoHS compliance     Yes
EU RoHS exemption clause     No
Frequency     50 Hz
In scope of WEEE     Yes
Parts Program name     EV210B, EV212B, EV220B 15 - 50, EV220B 6 - 22, EV220B 65 - 100,
EV222B, EV224B, EV227B, EV250B, EV251B
Power consumption 50Hz     21 VA
Power consumption 50Hz     12 W
REACH Candidate List substances     No
Rel. Humidity [max]     97 % RH
Rel. Humidity [min]     0 % RH
Rel. Humidity conditions     Non-condensation
Serviceable     No
Spare part number     018F6182
Supply voltage 50Hz Max      24 V
Supply voltage  AC     24 V
Type designation     BE024AS
